Uniview IPC2125SR3-ADPF40M-F IP Camera

The Uniview IPC2125SR3-ADPF40M-F is an outdoor fixed IP camera that offers 5.0 MP resolution, providing clear, high-quality surveillance. It is equipped with advanced features such as night vision, wide dynamic range, and motion detection, making it ideal for outdoor security applications.

Camera Performance

• Sensor: 1/2.7 Inch Progressive Scan CMOS for high-definition imaging.
• Resolution:
• 2592 x 1944 (5.0 MP) for sharp, detailed video.
• Other supported resolutions: 2560 x 1440, 2304 x 1296, 1920 x 1080 at up to 30fps.
• Shutter Speed: 1 - 1/100000s (Auto/Manual) for versatile shutter control.
• Slow Shutter: Yes, for enhanced low-light performance.
• Day & Night: Auto (ICR) for automatic day-night switching.
• Night Vision: Yes, with Black and White night vision for clear surveillance in low-light conditions.
• S/N Ratio: >52 dB for high-quality, noise-free video.

Lens & Viewing Capabilities

• Lens:
• Lens: 4mm for a moderate field of view.
• Focal Length: 4mm for standard viewing range.
• PTZ (Pan-Tilt-Zoom): No, this camera is fixed-lens.
• Viewing Angle:
• Pan: 0° to 360° for full horizontal rotation.
• Tilt: 0° to 90° for vertical adjustment.
• Rotate: 0° to 360° for complete rotational control.

Image & Video Quality

• Frame Rate:
• Main Stream: 5MP (2592 x 1944), Max 20fps; 4MP (2560 x 1440), Max 30fps; 3MP (2304 x 1296), Max 30fps; 1080P (1920 x 1080), Max 30fps for clear and smooth video.
• Video Type: Ultra 265, H.265, H.264, MJPEG for efficient video compression.
• Noise Reduction: 2D/3D NDR for improved video quality in low-light environments.
• Wide Dynamic Range (WDR): 120dB for enhanced image quality in high-contrast lighting.

Network & Connectivity

• Sim Supported: No.
• Interface(s): 1 x RJ45 10M/100M Base-TX Ethernet for stable wired network connections.
• Wi-Fi: No.
• Protocols: IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, SSL for secure communication.

Security Features

• Security:
• Password Protection, HTTPS Encryption, IP Address Filter, and Digest Authentication for secure access.
• Motion Detection: Supports up to 4 areas for customizable motion detection zones.
• Human Detection: Yes, for automated human recognition.
• Face Detection: Unmentioned.
• Watermark: Unmentioned.
• Lightning Protection: Unmentioned.
• Surge Protection: Unmentioned.
• Voltage Transient Protection: Unmentioned.
• Simultaneous Live View: Yes, for multiple users to view the feed simultaneously.

Storage & Audio

• Card Slot: Yes, supports MicroSD card (up to 256GB) for local storage.
• Storage Type: MicroSD.
• Mic & Speaker: Only Mic for audio capture.
• Audio Communication: No two-way audio.
• Input Trigger: Unmentioned.

Physical Build & Power

• Form Factor: Bullet for outdoor surveillance.
• Body Material: Metal for enhanced durability.
• Color: Black & White.
• Dimensions: 165 x 63.1 x 62.5mm.
• Weight: 450 gm.
• Relevant Accessories: Unmentioned.

Power & Environmental Conditions

• Power Supply: 12V DC +/- 5%.
• Approx. Power Consumption: 6.4W (Max.).
• Operating Temperature: -30°C to 60°C for outdoor use in extreme conditions.
• Operating Humidity: 95% or Less (Non-Condensing) for reliable performance in humid conditions.

Warranty

• 1 Year Warranty (without adapter).
