TP-Link VIGI C440I IP Camera

The TP-Link VIGI C440I is an indoor IP camera that delivers high-quality video surveillance with a 4.0 MP camera, infrared cut filter, and black and white night vision. This camera is a reliable solution for home or office security.

Camera Performance

• Sensor: 1/3 Inch Progressive Scan CMOS for detailed image capture.
• Resolution: 2560 x 1440 for high-definition video. Additional resolutions supported:
• 2304 x 1296, 2048 x 1280, 1920 x 1080, 1280 x 720, 640 x 480, 352 x 288, 320 x 240.
• Shutter Speed: 1/3 to 1/10000 s for sharp images even in low-light conditions.
• Slow Shutter: Yes for enhanced low-light performance.
• Day & Night: IR cut filter for accurate color reproduction during the day and at night.
• Night Vision: Yes, with Black and White Night Vision Mode for clear images in darkness.
• S/N Ratio: >52 dB for low noise in recordings.

Lens & Viewing Capabilities

• Lens:
• Lens: 2.8mm for a wide field of view.
• Focal Length: 2.8mm for a wide viewing angle.
• PTZ (Pan-Tilt-Zoom): No, fixed lens camera.
• Viewing Angle:
• Diagonal: 106.5°
• Horizontal: 88.8°
• Vertical: 48.9° for wide-area coverage.

Image & Video Quality

• Frame Rate:
• Main Stream:
• 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps.
• 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps.
• Sub-Stream:
• 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps.
• 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps.
• Video Type: H.265+/H.265/H.264+/H.264 for efficient video compression.
• Noise Reduction: Yes, for clearer video quality.
• Digital Noise Reduction (DNR): 3D DNR for low-light noise reduction.
• Wide Dynamic Range (WDR): Yes for better image detail in high-contrast lighting.

Network & Connectivity

• Sim Supported: No.
• Interface(s): RJ-45 (10/100 Base-T) for wired network connections.
• Wi-Fi: No.
• Protocols: TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS for secure communication.

Security Features

• Security:
• Password Protection, HTTPS Encryption, IP Address Filter, and Digest Authentication for secure access.
• Motion Detection: Yes, for automated event recording.
• Human Detection: Yes, for person detection.
• Face Detection: Unmentioned.
• Watermark: Unmentioned.
• Lightning Protection: Unmentioned.
• Surge Protection: Unmentioned.
• Voltage Transient Protection: Unmentioned.
• Simultaneous Live View: 3 Main Streams & 3 Sub-Streams for multiple simultaneous viewers.

Storage & Audio

• Card Slot: No.
• Storage Type: FTP for remote file storage.
• Mic & Speaker: No.
• Audio Communication: No, one-way audio only.
• Input Trigger: Unmentioned.

Physical Build & Power

• Form Factor: Dome for compact installation.
• Body Material: Plastic for lightweight construction.
• Color: White.
• Dimensions: 123 x 123 x 83mm.
• Weight: 190 gm.
• Relevant Accessories: Unmentioned.

Power & Environmental Conditions

• Power Supply: 12V DC +/- 5%, 5.5mm Coaxial Power Plug PoE.
• Approx. Power Consumption: 5W (Max.).
• Operating Temperature: -30°C to 60°C for use in various environments.
• Operating Humidity: 95% or Less (Non-Condensing).

Warranty

• 1 Year Warranty (without adapter).
