TP-Link VIGI C330 IP Camera

The TP-Link VIGI C330 is a high-performance outdoor IP camera designed for clear and reliable surveillance in all weather conditions. Equipped with a 3.0 MP camera, infrared cut filter, and color night vision, this camera offers enhanced security for your home or business.

Camera Performance

• Sensor: 1/2.8 Inch Progressive Scan CMOS for high-definition image capture.
• Resolution:
• 2304 x 1296 (3.0 MP) for detailed video quality.
• Additional resolutions supported: 2048 x 1280, 1920 x 1080, 1280 x 720, 704 x 576, 640 x 480, 352 x 288, 320 x 240.
• Shutter Speed: 1/3 to 1/10000 s for sharp images in various lighting conditions.
• Slow Shutter: Yes for better low-light performance.
• Day & Night: IR cut filter for color accuracy during the day and color night vision for clear night-time surveillance.
• S/N Ratio: >=52 dB for low-noise images with high-quality clarity.

Lens & Viewing Capabilities

• Lens:
• Lens: 2.8mm for a wide field of view.
• Focal Length: 2.8mm for a wide viewing angle.
• PTZ (Pan-Tilt-Zoom): No, fixed lens camera.
• Viewing Angle:
• Diagonal: 128.7° for broad coverage.

Image & Video Quality

• Frame Rate:
• 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps for flexible frame rate options based on your needs.
• Video Type: H.265+/H.265/H.264+/H.264 for efficient video compression and quality.
• Noise Reduction: Yes, for clearer video output.
• Digital Noise Reduction (DNR): 3D DNR for low-light noise reduction.
• Wide Dynamic Range (WDR): DWDR for enhanced detail in high-contrast environments.

Network & Connectivity

• Sim Supported: No.
• Interface(s): 1 x RJ45 10/100M Self-Adaptive Ethernet for stable wired connections.
• Wi-Fi: No.
• Protocols: TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS for secure communication.

Security Features

• Security:
• Password Protection, HTTPS Encryption, IP Address Filter, and Digest Authentication to ensure secure access.
• Motion Detection: Yes, for automated recording based on motion events.
• Human Detection: Yes, for person detection.
• Face Detection: Unmentioned.
• Watermark: Unmentioned.
• Lightning Protection: Unmentioned.
• Surge Protection: Unmentioned.
• Voltage Transient Protection: Unmentioned.
• Simultaneous Live View: 3 Main Streams & 3 Sub-Streams for multiple viewers simultaneously.

Storage & Audio

• Card Slot: No.
• Storage Type: None.
• Mic & Speaker: Only Mic, no speaker for two-way audio.
• Audio Communication: No, one-way audio.
• Input Trigger: Unmentioned.

Physical Build & Power

• Form Factor: Bullet for durable outdoor installation.
• Body Material: Plastic for lightweight construction.
• Color: Black & White.
• Dimensions: 174 x 78 x 71mm.
• Weight: 260 gm.
• Relevant Accessories: Unmentioned.

Power & Environmental Conditions

• Power Supply: 12V DC +/- 5%, 5.5mm Coaxial Power Plug PoE.
• Approx. Power Consumption: 5.4W (Max.).
• Operating Temperature: -30°C to 60°C for extreme weather conditions.
• Operating Humidity: 95% or Less (Non-Condensing).

Warranty

• 1 Year Warranty (without adapter).
