TP-Link EAP620 HD AX1800 Wireless Ceiling Mount Access Point
Key Specification
‣ Network Standards:
IEEE 802.11ax/ac/n/g/b/a
‣ Connectivity – Dual Band
‣ Data Transfer Rates – 1800 Mbps
‣ Interface(s) - 1 x
Gigabit Ethernet (RJ-45) Port
‣ Antenna (Type & Qty)
- 4 x Internal
Product Specification
|
Brand |
TP-Link |
|
Model |
TP-Link EAP620 HD |
|
P/N |
N/A |
|
Components* |
Network
Standards: IEEE 802.11ax/ac/n/g/b/a Data
Transfer Rates: 1800 Mbps WAN
Network Standard: No LAN
Network Standard: 10/100/1000 |
|
Interface |
Interface(s): 1 x Gigabit Ethernet (RJ-45)
Port Number of WAN Port: No Number of LAN Port: 1 USB Sharing Support: No |
|
Wireless |
Band:
Dual Frequency:
2.4GHz, 5GHz Bluetooth:
No Antenna
(Type & Qty): 4 x Internal Antenna
Gain: 2.4 GHz: 2 x 4 dBi, 5 GHz: 2 x 5 dBi Antenna
Placement: Internal MU-MIMO
Support: Yes Transmission
Power: CE: <20 dBm(2.4 GHz, EIRP), <23 dBm(5 GHz band1/2, EIRP) <25
dBm (5 GHz band3), FCC: <25 dBm (2.4 GHz), <25 dBm (5 GHz). |
|
Management |
SSID Numbers: 16 Management: Omada App, Omada Cloud-Based
Controller, Omada Hardware Controller (OC300), Omada Hardware Controller
(OC200), Omada Software Controller. Web-Based Management: HTTP/HTTPS Multi-Site Management: Yes Management MAC Access Control: Yes Remote Management: Yes |
|
Performance |
OFDM/OFDMA:
Yes Email
Alerts: Yes |
|
Technical Info |
System Requierment: Microsoft Windows XP,
Vista, Windows 7, Windows 8, Windows10, Linux |
|
Security |
Wireless
Security: WEP, WPA-Personal/Enterprise, WPA2-Personal/Enterprise,
WPA3-Personal/Enterprise |
|
Power Attributes |
Power Method: 12 V / 1.5 A DC Max. Power Consumption: EU: 14.4 W (For
PoE); 13.1 W (for DC), US: 14.9 W (For PoE); 13.4 W (for DC) Passive PoE Power Supply: 48V Passive PoE |
|
Environmental |
Operating
Temperature: 0 Degree C to 40 Degree C Operating
Humidity: 10% - 90% (non-condensing) Storing/Storage
Temperature: -40 Degree C to 70 Degree C Storing/Storage
Humidity: 5% - 90% RH (non-condensing) |
|
Physical Attributes |
Button: Reset Mounting: Yes Mount Options: Ceiling /Wall Mounting Dimensions: 160 x 160 x 33.6mm Color: White Packet Contents: EAP620 HD, Power Adapter,
Ceiling / Wall Mounting Kits, Installation Guide. |
|
Warranty |
2 year
(Without Adapter) |
|
* Product may vary with different Kit or Version |
|
Product Details
TP-Link
EAP620 HD Wireless Access Point
The TP-Link EAP620 HD is an
advanced dual-band wireless access point designed to provide
high-performance Wi-Fi with IEEE 802.11ax/ac/n/g/b/a standards. With 1800
Mbps of total throughput, it is ideal for high-density environments such as
offices, classrooms, and large homes, delivering stable and fast
wireless connectivity.
Features
- Network Standards:
Compatible with IEEE 802.11ax/ac/n/g/b/a, ensuring optimal
performance and device compatibility.
- Data Transfer Rates:
Supports 1800 Mbps, with 1200 Mbps on the 5 GHz band
and 574 Mbps on the 2.4 GHz band.
- Wireless Security:
Includes robust security features, supporting WEP, WPA-Personal/Enterprise,
WPA2-Personal/Enterprise, and WPA3-Personal/Enterprise for a
secure wireless network.
- MU-MIMO:
Supports MU-MIMO for efficient communication with multiple devices,
improving overall network efficiency.
- Antenna Configuration:
Equipped with 4 internal antennas, with 2 x 4 dBi for the 2.4
GHz band and 2 x 5 dBi for the 5 GHz band, enhancing
coverage and signal strength.
Design
& Build
- Dimensions:
160 x 160 x 33.6 mm, compact and designed for easy installation on ceiling
or wall.
- Color:
White, offering a neutral design that blends with most
environments.
- Mounting Options:
Ceiling or wall mounting options for flexible installation.
Power
& Environmental
- Power Supply:
12V/1.5A DC, with a 48V Passive PoE option for flexibility
in power supply.
- Max. Power Consumption: 14.4 W (for PoE), or 13.1 W (for DC),
making it energy-efficient.
- Operating Temperature:
0°C to 40°C for reliable performance in most indoor environments.
- Operating Humidity:
10% to 90% (non-condensing), suitable for a range of environments.
- Storage Temperature:
-40°C to 70°C, ensuring safe storage in varying conditions.
Performance
& Management
- Throughput:
1800 Mbps total bandwidth, split between 2.4 GHz (574
Mbps) and 5 GHz (1200 Mbps) bands.
- Web-Based Management:
Supports HTTP/HTTPS for easy remote management.
- Omada Management:
Compatible with Omada App, Omada Cloud-Based Controller, and
Omada Hardware Controllers (OC300/OC200) for centralized management
across multiple sites.
- Email Alerts:
Receive alerts via email for important network status updates.
Security
- Wireless Security:
The EAP620 HD supports modern wireless encryption standards including WPA3-Personal/Enterprise
and provides robust protection against unauthorized access.
- Access Control:
Offers MAC Access Control for additional security measures.
Package
Contents
- EAP620 HD Access Point
- Power Adapter
- Ceiling/Wall Mounting Kits
- Installation Guide
Warranty
- 2-year warranty
(excluding the adapter).
