TP-Link EAP225 AC1350 MU-MIMO Gigabit Ceiling Mount Wireless Access Point
Key Specification
‣ Network Standards:
IEEE 802.11a, b, g, n, ac
‣ Connectivity – Dual Band
‣ Data Transfer Rates – 1350 Mbps
‣ Interface(s) - 1 x
Gigabit Ethernet (RJ-45) Port
‣ Antenna (Type & Qty)
- 2 x Internal
Product Specification
|
Brand |
TP-Link |
|
Model |
TP-Link EAP225 AC1350 |
|
P/N |
N/A |
|
Components* |
Network
Standards: IEEE 802.11a, b, g, n, ac Data
Transfer Rates: 1350 Mbps LAN
Network Standard: 10/100/1000 |
|
Interface |
Interface(s): 1 x Gigabit Ethernet (RJ-45)
Port Number of WAN Port: No Number of LAN Port: 1 USB Sharing Support: No |
|
Wireless |
Supported
Protocols: MAC Filtering, SNMPv1, SNMPv2c Band:
Dual Frequency:
2.4GHz - 5GHz Bluetooth:
No Antenna
(Type & Qty): 2 x Internal Antenna
Gain: 4dBi Antenna
Placement: Internal MU-MIMO
Support: Yes Transmission
Power: <-24dBm(2.4GHz), <-22dBm(5GHz) |
|
Management |
Throughput: 1350 Mb/s Total, 2.4 GHz: 450
Mb/s, 5 GHz: 867 Mb/s SSID Numbers: Up to 16 SSIDs Web-Based Management: HTTP/ HTTPS Multi-Site Management: Yes Management MAC Access Control: Yes |
|
Performance |
Email
Alerts: Yes |
|
Technical Info |
System Requierment: Windows 7, 8, 10, Vista,
XP, Linux |
|
Security |
Wireless
Security: Captive Portal Authentication, Access Control, Wireless Mac Address
Filtering, Wireless Isolation Between Clients, SSID to VLAN Mapping, Rogue AP
Detection, 802.1X Support |
|
Power Attributes |
Power Method: 802.3af/at PoE, 24V Passive
PoE (+4,5pins; -7,8pins. PoE Adapter Included) Max. Power Consumption: 12.6W Passive PoE Power Supply: 802.3af/at |
|
Environmental |
Operating
Temperature: 0 Degree C to 40 Degree C Operating
Humidity: 10% - 90% (non-condensing) Storing/Storage
Temperature: -40 Degree C to 70 Degree C Storing/Storage
Humidity: 5% - 90% RH (non-condensing) |
|
Physical Attributes |
Button: Reset LED Indicators: Yes Mounting: Yes Mount Options: Ceiling /Wall Mounting Dimensions: 205.5 x 181.5 x 37.1mm Color: White Packet Contents: AC1350 Wireless MU-MIMO
Gigabit Ceiling Mount Access Point EAP225, Passive PoE Adapter, Power Cord,
Mounting Kits, Installation Guide. |
|
Warranty |
2 year
(Without Adapter) |
|
* Product may vary with different Kit or Version |
|
Product Details
TP-Link
EAP225 AC1350 Wireless Access Point
The TP-Link EAP225 AC1350 is
a high-performance dual-band wireless access point offering 1350 Mbps
of total throughput. With support for IEEE 802.11a/b/g/n/ac standards
and MU-MIMO technology, this device ensures seamless performance across
both 2.4 GHz and 5 GHz frequencies.
Features
- Network Standards:
Compatible with IEEE 802.11a/b/g/n/ac for broad wireless device
compatibility.
- Data Transfer Rates:
Delivers up to 450 Mbps on 2.4 GHz and 867 Mbps on 5
GHz, ensuring high-speed wireless performance.
- Wireless Security:
Features Captive Portal Authentication, Access Control, MAC
Address Filtering, Wireless Isolation Between Clients, SSID
to VLAN Mapping, Rogue AP Detection, and 802.1X support
for secure and robust wireless environments.
- Antenna:
Equipped with 2 internal antennas with a gain of 4 dBi for
optimized signal strength and coverage.
- MU-MIMO Support:
Yes, improving simultaneous data transmission to multiple clients for
better network efficiency.
Design
& Build
- Dimensions:
205.5 x 181.5 x 37.1mm, designed for easy ceiling or wall mounting.
- Color:
White, providing a neutral aesthetic that blends in with most
environments.
- Mounting:
Ceiling or wall mounting for flexible installation options.
Power
& Environmental
- Power Supply:
Supports 802.3af/at PoE and 24V Passive PoE, with the PoE
adapter included in the package. Max. Power Consumption is 12.6W.
- Operating Temperature:
Works in environments ranging from 0°C to 40°C.
- Operating Humidity:
Can operate in 10% to 90% humidity (non-condensing).
- Storage Temperature:
Suitable for storage at -40°C to 70°C with 5% to 90% humidity
(non-condensing).
Performance
& Management
- Throughput:
Offers a total of 1350 Mbps with 450 Mbps on the 2.4 GHz
band and 867 Mbps on the 5 GHz band for excellent speed and
performance.
- SSID:
Supports up to 16 SSIDs, ideal for creating multiple networks with
distinct configurations.
- Multi-Site Management:
Can be managed remotely across multiple sites for easier network
management.
- Web-Based Management:
Supports HTTP/HTTPS access for remote configuration and monitoring.
- Email Alerts:
Provides email alerts for important notifications related to system
status.
- MAC Access Control:
Allows for additional network security through MAC address control.
Security
- Wireless Security:
In addition to WPA/WPA2 encryption, it offers advanced features such as Wireless
Isolation and Rogue AP Detection for a secure wireless network.
- Protocols:
Supports MAC Filtering, SNMPv1, and SNMPv2c for
additional network security and monitoring.
Package
Contents
- AC1350 Wireless MU-MIMO Gigabit Ceiling Mount Access
Point EAP225
- Passive PoE Adapter
- Power Cord
- Mounting Kits
- Installation Guide
Warranty
Comes with a 2-year warranty
(excluding the adapter).
