Brand

NZXT

Model

NZXT H9 Flow

Series

Gaming

Type

Mid Tower

Technical Data

Supported Motherboard Type: E-ATX (Up to 277mm), ATX, Micro-ATX, Mini-ITX

Supported LED Strip: Unmentioned

Fan / Light Controller: Unmentioned

Back-Connect Supported: Yes

Graphics-Card Length: 459mm

Supported CPU Cooler: Air Cooler or Liquid Cooler

CPU Cooler Height: 165mm

PSU Length: 200mm

Interfaces & Slots

Front/Top USB port: 2 x USB 3.2 Type-A, 1 x USB 3.2 Gen 2x2 Type-C

Front/Top Audio Port: 1 x Headset Jack

3.5 Inch Drive Bay: 2

2.5 Inch Drive Bay: 4+2

Expansion Slots: 7

Optical Drive Bay: No

Cooling System Data

Cooling Fan (Built-In): 4

Additional Fan Slot: 6

Pre-Installed Fan Size: Front-Right: 3 x 120mm / 3 x 140mm, Rear: 1 x 120mm

Supported Fan Size: Top: 3 x 120mm / 3 x 140mm, Bottom: 3 x 120mm / 3 x 140mm

Lighting Fan: No

Radiator Support Front/Top/Rear: Front-Right: Up to 420mm, Top: Up to 420mm, Bottom: Up to 360mm, Rear: Up to 120mm

Radiator Support Max.: Up to 420mm

Power Data

Power Supply (Built-In): No

Approx. Power Consumption: 20W

Physical Atributes

Transparent Side Window: Yes

Case Windowed: Tempered Glass Window

Material: SGCC steel, clear tempered glass (white), tinted tempered glass (black)

Color: Black

Dimensions: 506 x 315 x 481mm

Weight (Kg): 12.46 kg

Handle: No

Extra Data

Others

Fan Specs - F140Q (CV): Speed1,350 -/+ 150 RPM, Airflow: 100.25 CFM, Static Pressure: 1.4 mmH2O, Noise: 22.9 dBA, Fan Connector: 3-pin. Fan Specs - F120Q (CV): Speed: 1,350 -/+ 150 RPM, Airflow: 60.2 CFM, Static Pressure: 1.05 mmH2O, Noise: 24.1 dBA, Fan Connector: 3-pin. Inside the Box: H9 Flow x 1, Pre-installed F140Q (CV) x 3, Pre-installed F120Q (CV) x 1, Installation accessories x 1, Installation accessories x 1.

Specialty

Dual-Chamber Design: Separates main components from the PSU and drives for improved thermal performance and cable management. Optimized Airflow: Perforated steel panels and angled front-right fans ensure efficient cooling for high-performance builds. Pre-Installed Fans: Includes three F140Q (CV) fans in the front-right and one F120Q (CV) fan in the rear. CV = Case Version (3-pin DC). Ten-Fan Capacity: Supports up to nine 140mm fans across the top, front-right, and bottom, plus one 120mm fan in the rear. Panoramic View: Showcase every detail of your build with seamless, wraparound tempered glass paneling. Large Radiators & GPUs: Fits up to a 420mm radiator on the top and front-right, with plenty of clearance for high-end graphics cards. Easy Cable Management: Extra-wide channels, built-in Velcro straps, and tie-down points make cable routing effortless. Back-Connect Ready: Compatible with rear-connecting motherboards like ASUS BTF and MSI Project Zero for a cable-free look. Optimized Airflow, Mesh Panels, Large Radiator Support, Maximum Graphics, Easy Cable Management.

Warranty

No warranty

* Product may vary with different Kit or Version
