MSI PRO B860-P DDR5 (Intel Core Ultra LGA1851 Socket) ATX Motherboard
Key Specification
Product Specification
|
Brand |
MSI |
|
Model |
MSI PRO B860-P (Wi-Fi 7) |
|
Color |
Black |
|
CPU Data |
Chipset Brand: Intel Chipset: Intel B860 Sockets Supported: LGA1851 Built-in Processor: N/A Supported CPU: Intel Core Ultra
Processors (Series 2) Generation: Ultra |
|
Memory
Support |
Memory Type: DDR5 Memory MHz: 8800 - 6400 (OC) MT/s/ 6400 -
4800 (JEDEC) MT/s Memory Channel: Dual Memory Slot: 4 Memory Max: 256GB |
|
Storage Info |
Storage Interface: 6.0Gb/s M.2/SSD Expansion Slot: 3 M.2/SSD Expansion : 3 x M.2 (1 x M.2
supports up to PCIe 5.0 x4 , supports 2280/2260/2242 devices, 1 x M.2
supports up to PCIe 4.0 x4 , supports 2280/2260 devices, 1 x M.2 supports up
to PCIe 4.0 x2 , supports 2280 devices) |
|
Graphics
Info |
Multi-GPU Support: N/A PCI Express Slot: 4x PCI-E x16 slot (PCI_E1
Gen PCIe 5.0 supports up to x16 (From CPU), PCI_E2 Gen PCIe 4.0 supports up
to x1 (From Chipset), PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset),
PCI_E4 Gen PCIe 4.0 supports up to x1 (From Chipset)) |
|
Audio & Video |
Audio Chipset: REALTEK ALC897 Codec Audio Channel – 7.1 |
|
Network
& Connectivity |
LAN Chipset: Realtek 8126 5Gbps LAN LAN Speed (Mbps): 5Gbps WiFi: Yes WiFi Technology: Intel Wi-Fi 7 Bluetooth: Bluetooth 5.4 |
|
Ports Data |
USB Port: 4x USB 2.0 Type-A, 2x USB
5Gbps Type-A, 2x USB 10Gbps Type-A, 1x Thunderbolt 4 40Gbps (Type-C) VGA Port: N/A HDMI Port: 1 Display: 1 SATA Port: 4 Thunderbolt: 1 TPM Port: 1 |
|
Technical
Data |
Cable Management: Front Heatsink: Yes RGB Support: ARGB RGB Connector: 2 x Addressable V2 RGB LED
connector (JARGB_V2), 1 x RGB LED connector(JRGB) Approx. Power Consumption: 70W Form Factor: ATX |
|
Compatibility |
Supported Operating System: Windows 11 Supported Operating System: Supports
Intel Core Ultra Processors (Series 2) |
|
Warranty |
3 year |
|
* Product
may vary with different Kit or Version |
|
Product Details
MSI
PRO B860-P (Wi-Fi 7) ATX Motherboard
The MSI PRO B860-P (Wi-Fi 7)
is an advanced ATX motherboard designed to power up the latest Intel
Core Ultra Series 2 processors using the new LGA1851 socket.
Offering a professional-grade blend of performance, speed, and connectivity,
this motherboard supports DDR5 memory, ultra-fast PCIe 5.0 M.2
storage, and next-gen Wi-Fi 7. It’s an excellent choice for
business-grade desktops, content creators, and modern multitaskers looking for
stability and future-proof features.
Features
- Intel B860 Chipset:
Engineered for the newest Intel Core Ultra (Series 2) CPUs.
- LGA1851 CPU Socket:
Supports the latest Intel generation with improved power efficiency and
performance.
- DDR5 Memory Support:
Accommodates memory speeds from 8800 MT/s (OC) to 4800 MT/s
(JEDEC), with up to 256GB capacity over 4 dual-channel DIMMs.
- PCIe Expansion:
- PCI_E1:
Gen 5.0 x16 (from CPU)
- PCI_E2 & PCI_E4:
Gen 4.0 x1 (from chipset)
- PCI_E3:
Gen 4.0 x4 (from chipset)
Storage
and Expansion
- Triple M.2 Slots:
- 1 x PCIe 5.0 x4
(2280/2260/2242)
- 1 x PCIe 4.0 x4
(2280/2260)
- 1 x PCIe 4.0 x2
(2280)
- 4 x SATA III 6Gb/s
ports for traditional SSDs and HDDs.
Graphics
and Display
- Integrated Graphics Output: 1 x HDMI port for processors with integrated
GPU support.
- Multi-GPU Setup:
Not officially supported, but flexible expansion options via PCI-E slots.
Network
and Connectivity
- Realtek 8126 5G LAN:
Provides ultra-fast and reliable wired networking at 5Gbps.
- Intel Wi-Fi 7:
Next-generation wireless standard for maximum throughput and reduced
latency.
- Bluetooth 5.4:
Enhanced pairing speed and longer range.
Connectivity
Options
- USB Ports:
- 4 x USB 2.0 Type-A
- 2 x USB 5Gbps Type-A
- 2 x USB 10Gbps Type-A
- 1 x Thunderbolt 4 (40Gbps) Type-C
- Video Output:
1 x HDMI
- SATA Ports:
4
- Thunderbolt Ports:
1
- TPM Header:
For secure encryption and Windows 11 compliance
Design
and Build
- Form Factor:
ATX for full-sized PC builds with room for future upgrades.
- Color Scheme:
Sleek black finish, maintaining a professional and clean aesthetic.
- RGB Lighting Support:
- 2 x Addressable RGB (JARGB_V2) connectors
- 1 x RGB LED connector (JRGB)
- Heatsink Design:
Ensures optimal thermal performance under heavy loads.
- Cable Routing:
Designed with front cable management support for a clean internal layout.
Power
and Efficiency
- Power Draw:
Approx. 70W, providing balanced energy usage for high-performance
setups.
- Thermal Optimization:
Heat sinks and design layout allow for efficient heat dissipation.
Compatibility
and Warranty
- OS Support:
Fully compatible with Windows 11
- CPU Compatibility:
Supports Intel Core Ultra Series 2 processors on LGA1851
- Warranty:
Includes a 3-year manufacturer warranty
Price
and Availability
The MSI PRO B860-P (Wi-Fi 7) motherboard is available now at Computer Village Agrabad, Chattogram, Bangladesh. Please check with the store for current pricing and availability.
