Mikrotik CRS309-1G-8S+IN 9-Port Managed Cloud Router Switch with Router OS
Key Specification
‣Ports: 1
× Gigabit Ethernet (RJ-45) + 8 × 10G SFP+
‣PoE: Yes
— Passive PoE and 802.3af/at compliant
‣Network Standards:
IEEE 802.3, 802.3u, 802.3ab, 802.3z, 802.3x
‣Data Transfer Rate:
10 Gbps per SFP+ port; 1 Gbps for Ethernet port
‣Form Factor: Desktop or
rackmountable; dimensions: 272 × 191 × 44 mm
Product Specification
|
Category |
Details |
|
Brand
/ Model / P/N |
MikroTik
CRS309-1G-8S+IN |
|
Type |
Managed Cloud Router / Switch (Layer-2 / partial Layer-3
via RouterOS) |
|
Ports
& Interfaces |
•
1 × 1 Gbps RJ-45 Ethernet port (for management) • 8 × 10 Gbps SFP+ ports •
RS-232 serial (console) port • Grounding terminal |
|
CPU / Memory / Storage |
CPU: Dual-core 98DX8208 @ 800 MHz RAM: 512 MB Flash
storage: 16 MB |
|
Operating
Systems / Dual Boot |
RouterOS
(MikroTik) / SwOS (switch-oriented OS) License Level 5 |
|
Switching Capacity &
Performance |
Non-blocking Switching Capacity: ~162 Gbps Total
Non-blocking Throughput: ~81 Gbps |
|
Power
& Power Inputs |
•
DC jack input: 12-57 V • PoE-IN: 802.3af/at compliant (18-57 V) • Number of
DC inputs: 2 (DC jack + PoE) • Power consumption: ~23 W (max), ~17 W without
attachments/adapters |
|
Physical Attributes |
Dimensions: ~272 × 191 × 44 mm Enclosure acts as passive
heatsink (fanless) Rack ears included MTBF: ~200,000 hours at 25 °C |
|
Environmental
Ratings |
Operating
temperature: -40 °C to +70 °C Certifications: CE, EAC, RoHS IP20 enclosure
rating |
|
Other Features |
• CPU temperature monitor • Beeper (boot / status) • Dual
boot option between SwOS / RouterOS • Management via Web / WinBox / CLI
depending on OS |
|
Warranty
/ Support |
Included
power adapter, mounting hardware, etc. Warranty and support per MikroTik /
vendor policy |
* Product may vary with different Kit or
Version
Product Details
MikroTik CRS309-1G-8S+IN 9-Port
Managed Cloud Router Switch (RouterOS + SwitchOS)
The MikroTik CRS309-1G-8S+IN
is a high-performance Cloud Router Switch that combines the power of RouterOS
with the simplicity of SwitchOS, giving you the flexibility to choose
between advanced routing features or streamlined switching operations. It is
equipped with 8 × 10G SFP+ ports and 1 × Gigabit RJ45 Ethernet port,
delivering massive throughput, low latency, and enterprise-grade
reliability—ideal for datacenters, ISPs, and demanding enterprise
networks.
Key Features & Benefits
- 9 Ports Total
– 8 × 10G SFP+ ports and 1 × Gigabit RJ45 port for
management or uplink.
- Dual OS Flexibility
– Run RouterOS for advanced Layer 3 features or SwitchOS for
simplified configuration.
- High Switching Capacity – Supports 162Gbps switching, 81Gbps
forwarding rate, and 178Mpps packet forwarding.
- Fanless Cooling
– Silent operation with passive cooling and heatsink design.
- Compact Metal Case
– Durable and space-saving desktop/rackmount form factor.
- Power over Ethernet (PoE-In) – 802.3af/at support on the Gigabit Ethernet port.
- Energy-Efficient
– Max power consumption only 23W with all ports running at full
load.
- Advanced Features
– VLANs, ACLs, QoS, routing protocols, firewall, and more (when using
RouterOS).
Specifications
- Model:
CRS309-1G-8S+IN
- Type:
Layer 3 Managed Cloud Router Switch
- Operating System:
RouterOS / SwitchOS (dual boot)
- Ports:
8 × SFP+ (10G), 1 × Gigabit RJ45
- Switching Capacity:
162Gbps
- Forwarding Rate:
81Gbps
- Packet Forwarding:
178Mpps
- Cooling:
Passive, fanless design
- Power Supply:
External, with PoE-In support
- Dimensions:
141 × 115 × 44 mm
- Color:
Metallic gray
Why Choose MikroTik CRS309-1G-8S+IN?
- Combines routing and switching in one powerful
device.
- Perfect for high-speed 10G networks, datacenters,
and enterprise backbones.
- Silent, compact, and energy-efficient design.
- Backed by MikroTik’s robust RouterOS features
and flexible SwitchOS management.
Shop Now at Computer Village Agrabad
Get the MikroTik CRS309-1G-8S+IN 9-Port Managed Cloud Router Switch at Computer
Village Agrabad, Wali Mansion, 600 Sk. Mujib Road, Chowmohoni, Agrabad,
Chattogram.
We provide fast delivery across Bangladesh, including Dhaka,
Chattogram, Sylhet, Rajshahi, Khulna, and Barisal.
