Mikrotik cAP lite Single Band Dual-Chain Wireless Ceiling Access Point #RBcAPL-2nD
Key Specification
‣ Connectivity – Single
Band
‣ Network Standards - 802.11b/g/n
‣ Data Transfer Rates -
300 Mbps
‣ Interface(s) - 1 x
10/100 Ethernet ports
‣ Antenna (Type & Qty)
- Unmentioned
Product Specification
|
Brand |
Mikrotik |
|
Model |
Mikrotik cAP lite |
|
P/N |
RBcAPL-2nD |
|
Components* |
Network
Standards: 802.11b/g/n Data
Transfer Rates: 300 Mbps LAN
Network Standard: 10/100 Processor:
QCA9533 Memory:
64MB Storage
(MB/GB/TB): 16MB Storage
Type: FLASH |
|
Interface |
Interface(s): 1 x 10/100 Ethernet ports Number of WAN Port: No Number of LAN Port: 1 |
|
Wireless |
Band: Single Frequency:
2.4GHz Bluetooth:
No Antenna
(Type & Qty): Unmentioned Antenna
Gain: 1.5dBi Antenna
Placement: Internal MU-MIMO
Support: No |
|
Management |
Operating Mode: Access Point |
|
Performance |
Protection:
No Waterproof
Level/Grade: IP20 IP
Rating: IP20 |
|
Technical Info |
Ideal Use: Business and Home users. MTBF: 100000 Hours |
|
Security |
Physical
Security Lock: No |
|
Power Attributes |
Power Method: 5V DC, PoE-IN Max. Power Consumption: 4 W AC Input Power: 100-240VAC, 50/60Hz DC Input Power: 5V Power Adapter Output: 5V Passive PoE Power Supply: 10 - 60V |
|
Environmental |
Operating
Temperature: -40 to 70 Degree C |
|
Physical Attributes |
Mounting: Yes Mount Options: Ceiling /Wall Mounting Dimensions: Wall case: 88 x 52 x 20mm
Ceiling case: 88 x 20mm Color: White Packet Contents: Mikrotik cAP lite Access
Point, User manual |
|
Warranty |
1 year (Without Adapter) |
|
* Product may vary with different Kit or
Version |
|
Product Details
Mikrotik
cAP lite Compact Ceiling-Mount Access Point
The Mikrotik cAP lite is an
ultra-compact wireless access point designed for seamless Wi-Fi
coverage in homes, businesses, hotels, and public spaces. With its discreet
ceiling or wall-mountable design, this lightweight yet powerful AP
delivers stable 2.4GHz Wi-Fi connectivity and supports Power over
Ethernet (PoE) for flexible installation.
Features
- Compact and Discreet Design, perfect for ceiling or wall mounting
- 802.11b/g/n Wireless Standard with 300 Mbps data rate for smooth browsing
and streaming
- 2.4 GHz Single-Band Operation, providing wide-range coverage
- Integrated Internal Antenna (1.5 dBi) for optimized signal distribution
- Passive PoE Support (10-60V) allows flexible installation without separate power
cables
- 1× 10/100 Mbps Ethernet Port for reliable wired connectivity
- IP20 Rated
for indoor use
- Ideal for Business and Home Environments requiring basic Wi-Fi coverage
Design
& Build
The Mikrotik cAP lite
features a minimalist and compact design, making it ideal for
unobtrusive ceiling or wall mounting. Its white finish blends
seamlessly with various interior styles, ensuring it doesn’t stand out in
public areas.
- Mounting Options:
Ceiling or Wall Mounting
- Antenna:
Internal, 1.5 dBi Gain for stable connectivity
- Dimensions:
- Wall Case:
88 × 52 × 20mm
- Ceiling Case:
88 × 20mm
- Color:
White, designed to blend with different environments
Performance
& Connectivity
This Wi-Fi access point
delivers stable wireless performance with optimized coverage for small
to medium spaces.
- Network Standards:
802.11b/g/n
- Maximum Data Transfer Rate: 300 Mbps
- Frequency Band:
2.4 GHz (Single Band)
- MU-MIMO Support:
No
- Ports:
- 1× 10/100 Mbps LAN Port
- IP Rating:
IP20 (For indoor use only)
Power
& Environmental Conditions
The cAP lite supports multiple
power input methods, including PoE and DC power, making it
versatile for different installations.
- Power Input:
- 5V DC
- Passive PoE (10-60V)
- Maximum Power Consumption: 4W
- Operating Temperature:
-40°C to 70°C, ensuring reliable performance in extreme
conditions
Package
Contents
- 1× Mikrotik cAP lite Access Point
- 1× User Manual
Warranty
- 1-Year Warranty (Without Adapter)
