Maxsun Challenger B760M-N D5 Intel Motherboard #MS-CHALLENGER B760M-N D5

(0 reviews)

Key Specification

  Chipset -  Intel B760

  Sockets Supported - LGA1700

  Supported CPU - 13th and 12th Generation Intel Core, Pentium Gold and Celeron Processors

  Generation – 12th/13th

  Memory Slot - 2

  Memory Max - 96GB

  Form Factor - Micro-ATX



Contact : 01713-240726
Price
৳12,800.00 /1
Quantity
Total Price
Share

Product Specification

Brand

Maxsun

Model

Maxsun Challenger B760M-N D5

Color

Black

CPU Data

Chipset Brand: Intel

Chipset: Intel B760

Sockets Supported: LGA1700

Built-in Processor: N/A

Supported CPU: 13th/ and 12th Generation Intel Core, Pentium Gold and Celeron Processors

Generation: 12th/13th

Memory Support

Memory Type: DDR5

Memory MHz: 6000(OC)/ 5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200(JEDEC)/ 5000(JEDEC)/ 4800(JEDEC) MHz

Memory Channel: Dual

Memory Slot: 2

Memory Max: 96GB

Storage Info

Storage Interface: 6Gb/s,

M.2/SSD Expansion Slot: 2

M.2/SSD Expansion : 2 x M.2 (1 x M.2 type 2242/2280 (supports PCIe 4.0 x4 mode)), (1 x M.2 type 2242/2280 (supports PCIe 4.0 x4 mode))

Graphics Info

Multi-GPU Support: N/A

PCI Express Slot: 1 x PCIe 4.0 x16 slot, 1 x PCIe 3.0 x4 slot

Audio & Video

Audio Chipset: Realtek ALC897 Codec

Audio Channel –5.1

Network & Connectivity

LAN Chipset: Realtek RTL8111H 1G LAN

LAN Speed (Mbps): 0/100/1000 Mbps

Ports Data

USB Port: 4 x USB 3.2 Gen1 Type A, 2 x USB 2.0

VGA Port: 1

HDMI Port: 1

Display: N/A

TPM: 1

SATA Port: 3

Technical Data

Cable Management: Front

RGB Support: RGB

Approx. Power Consumption: 60W

Form Factor: Micro-ATX

Compatibility

Supported Operating System: Windows 10 / Windows 11

Compatible Products: Raptor Lake Refresh 14600K, Core i3 12100F, Core i3 13100F, Core i5 12400F, Core i5 13400F, Core i5 13500, Core i7 13700KF etc Intel Core Processors, Pentium Gold and Celeron Processors

Warranty

3 year

* Product may vary with different Kit or Version

Product Details

Maxsun Challenger B760M-N D5 Micro-ATX Motherboard

The Maxsun Challenger B760M-N D5 motherboard is designed for users who require a powerful and cost-effective solution for building a system based on Intel's 12th and 13th Gen Core processors. This motherboard offers solid performance, versatile storage options, and modern connectivity for both gaming and productivity tasks.

Features

Supporting DDR5 memory, the Maxsun Challenger B760M-N D5 motherboard offers speeds up to 6000MHz (OC), ensuring high performance for demanding applications. It has 2 memory slots with a maximum capacity of 96GB, making it ideal for multitasking and heavy workloads.

Storage and Expansion

The motherboard comes with 2 M.2 slots for high-speed SSD expansion. Both M.2 slots support PCIe 4.0 x4 mode, enabling fast read and write speeds for enhanced system responsiveness. Additionally, the motherboard features 3 SATA ports for additional storage drives, providing ample space for your storage needs.

Graphics and Expansion

For graphics, the Maxsun Challenger B760M-N D5 offers a PCIe 4.0 x16 slot for a dedicated GPU, as well as a PCIe 3.0 x4 slot for expansion cards. While it doesn't support multi-GPU setups, the available PCIe slots offer sufficient flexibility for your graphics card and other expansion devices.

Networking and Audio

The motherboard uses the Realtek RTL8111H chipset for 1GbE LAN, ensuring reliable network connectivity for everyday tasks. For audio, it utilizes the Realtek ALC897 codec, which delivers 5.1-channel surround sound, providing an immersive experience for both work and play.

Ports and Connectivity

The Maxsun Challenger B760M-N D5 features a solid selection of ports, including 4 USB 3.2 Gen1 Type-A ports, 2 USB 2.0 ports, 1 VGA port, and 1 HDMI port for display options. The motherboard also supports RGB lighting, giving you the flexibility to customize your PC build's aesthetic.

Build and Design

The Maxsun Challenger B760M-N D5 comes in a sleek black color and is built in the Micro-ATX form factor, which is perfect for smaller PC cases. Its compact design doesn't compromise on performance or expansion options, and it also features front cable management for improved system organization.

Compatibility and Warranty

The motherboard supports Windows 10 and Windows 11 operating systems and is compatible with a wide range of 12th and 13th Gen Intel Core processors, including popular models like the Core i5, i7, and i9 series, as well as Pentium Gold and Celeron processors. With a 3-year warranty, users can be confident in the reliability and durability of the product.

Price and Availability

The Maxsun Challenger B760M-N D5 motherboard is available at Computer Village Agrabad, Chattogram, Bangladesh. Please contact the retailer for pricing and availability details.
