Hikvision DS-2CD1T47G2H-LIU (4mm) (4.0MP) ColorVu Smart Hybrid Light Bullet IP Camera
Key Specification
‣ Usage - Outdoor
‣ Form-Factor - Bullet
‣ Mega Pixels (MP) - 4.0
‣ Night Vision Mode - Black
and White
‣ Working Distance – 77
Meter
Product Specification
|
Brand |
Hikvision |
|
Model |
Hikvision
DS-2CD1T47G2H-LIU |
|
Usage |
Outdoor |
|
Type |
IP
Camera |
|
Camera |
Number of Camera: 1 Camera Type: Fixed Mega Pixels (MP): 4.0 Max. Camera Resolution: 2560 x 1440 Secondary Camera Type: Not Applicable Secondary Camera Mega Pixel (MP): Not
Applicable Secondary Camera Max Resolution: Not
Applicable Sensor Type: 1/3 Inch Progressive Scan CMOS Resolution: Main Stream: 50 Hz: 20 fps (2560
x 1440), 25 fps (1920 x 1080, 1280 x 720), 60 Hz: 20 fps (2560 x 1440), 24
fps (1920 x 1080, 1280 x 720), Sub-Stream: 50 Hz: 25 fps (1280 x 720, 640 x
480, 640 x 360), 60 Hz: 24 fps (1280 x 720, 640 x 480, 640 x 360) Shutter Speed: 1/3s to 1/100,000s Slow Shutter: Yes Day & Night: IR cut filter Night Vision: Yes Night Vision Mode: Black and White S/N Ratio: >52 dB |
|
Lens |
Number
of Lens: Single Lens (Primary) Lens: 4.8mm Focal
Length: 4.8 mm to 120 mm PTZ: No Zoom: Unmentioned Viewing
Angle: 94 Degree (H), 50 Degree (V), 110 Degree (D) |
|
Image |
Triple-Stream: Unmentioned Frame Rate - Unmentioned Noise Reduction: Yes Digital Noise Reduction (DNR): 3D DNR Wide Dynamic Range (WDR): 120 dB |
|
Network
& Connectivity |
Sim
Supported: No Sim
Network Type: Not Applicable Interface(s):
1 x RJ45 10M/100M self-adaptive Ethernet port Wi-Fi: No Wi-Fi
Details: No |
|
Security |
Security: Password protection, complicated
password, watermark, basic and digest authentication for HTTP, WSSE and
digest authentication for Open Network Video Interface, security audit log,
host authentication (MAC address) Password Protection: Yes Watermark: Yes Motion Detection: Yes Human Detection: Yes Face Detection: Unmentioned Lightning Protection: Unmentioned Surge Protection: Unmentioned Voltage Transient Protection: Unmentioned Simultaneous Live View: Up to 6 channels |
|
Technical
Data |
Video
Type: Main stream: H.265+/ H.265/ H.264+/ H.264, Sub-stream: H.265/ H.264/
MJPEG Mic
& Speaker: Only Mic Audio
Communication: No Input
Trigger: Unmentioned Working
Distance: 77 Metter Protocols:
IPv4, IPv6, TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, RTCP, NTP, IGMP, UDP,
QoS, FTP, SMTP, UPnP |
|
Physical Attributes |
Form-Factor: Bullet Card Slot: No Storage Type: FTP Storage Supported: Unmentioned Body Material: Metal + Plastic Color: Black & White Dimensions: 81 x 83.7 x 201.96mm Weight (gm): 550 gm Relevant Accessories (Not Included): Unmentioned |
|
Power |
Power: 12
VDC +- 25%, 0.57 A, max. 6.8 W, 5.5 mm coaxial power plug, reverse polarity
protection, PoE: IEEE 802.3af, Class 3, max. 8.3 W Battery
Capacity: Not Applicable Battery
Backup: No Battery
Backup Time: Not Applicable Power
Supply: 12 VDC +/- 25%, 0.57 A, max. 6.8 W, 5.5 mm coaxial power plug, reverse
polarity protection, PoE: IEEE 802.3af, Class 3, max. 8.3 W Approx.
Power Consumption: 6.8W Operating
Temperature: -30 Degree C to 65 Degree C Operating
Humidity: Humidity 95% or less (non-condensing) |
|
Warranty |
1 Year (Without Adapter) |
|
* Product may vary with
different Kit or Version |
|
Product Details
Hikvision
DS-2CD1T47G2H-LIU Outdoor IP Camera
The Hikvision DS-2CD1T47G2H-LIU
is a 4.0MP high-resolution outdoor bullet IP camera with smart human
detection, motion detection, and excellent low-light performance. It
provides clear night vision in black and white mode and includes advanced
security features, making it ideal for professional surveillance
applications.
Camera
Performance
- Sensor:
1/3 Inch Progressive Scan CMOS for high-definition imaging.
- Resolution:
2560 x 1440 (Main Stream).
- Frame Rate:
- Main Stream:
- 50Hz:
20 fps (2560 x 1440), 25 fps (1920 x 1080, 1280 x 720).
- 60Hz:
20 fps (2560 x 1440), 24 fps (1920 x 1080, 1280 x 720).
- Sub-Stream:
- 50Hz:
25 fps (1280 x 720, 640 x 480, 640 x 360).
- 60Hz:
24 fps (1280 x 720, 640 x 480, 640 x 360).
- Shutter Speed:
1/3s to 1/100,000s.
- Slow Shutter:
Yes.
- Day & Night:
IR cut filter for automatic switching.
- Night Vision:
Yes.
- Night Vision Mode:
Black & White.
- S/N Ratio:
>52 dB, ensuring minimal noise in low-light conditions.
Lens
& Viewing Capabilities
- Lens:
4.8mm.
- Focal Length:
4.8mm to 120mm.
- PTZ (Pan-Tilt-Zoom):
No.
- Zoom:
Unspecified.
- Viewing Angles:
- Horizontal:
94°.
- Vertical:
50°.
- Diagonal:
110°.
& Video Quality
- Noise Reduction:
3D Digital Noise Reduction (DNR).
- Wide Dynamic Range (WDR): 120 dB, improving performance in high-contrast
lighting.
- Triple-Stream:
Unspecified.
Network
& Connectivity
- Ethernet Port:
1 x RJ45 10M/100M self-adaptive Ethernet port.
- Wi-Fi:
No.
- Supported Protocols:
IPv4, IPv6, TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, RTCP, NTP, IGMP,
UDP, QoS, FTP, SMTP, UPnP.
Security
Features
- Password Protection:
Yes.
- Security Protocols:
Watermark, basic and digest authentication for HTTP, WSSE and digest
authentication for Open Network Video Interface, security audit log, host authentication
(MAC address).
- Motion Detection:
Yes.
- Human Detection:
Yes.
- Face Detection:
Unspecified.
- Simultaneous Live View: Up to 6 channels.
Storage
& Audio
- Card Slot:
No.
- Storage Type:
FTP.
- Storage Supported:
Unspecified.
- Mic & Speaker:
Only Mic.
- Audio Communication:
No.
- Input Trigger:
Unspecified.
- Working Distance:
77 meters.
Physical
Build & Power
- Form Factor:
Bullet, ideal for outdoor installations.
- Body Material:
Metal + Plastic.
- Color:
Black & White.
- Dimensions:
81 x 83.7 x 201.96mm.
- Weight:
550 gm.
- Relevant Accessories:
Unspecified.
Power
& Environmental Conditions
- Power Supply:
- 12VDC ± 25%, 0.57 A, max. 6.8 W.
- PoE Power Consumption: 8.3W.
- Direct Power Consumption: 6.8W.
- Operating Temperature:
-30°C to 65°C.
- Operating Humidity:
Up to 95% (non-condensing).
Warranty
- 1 Year Warranty
(without adapter).
