Hikvision DS-2CD1T43G2-LIU Indoor & Outdoor IP Camera

The Hikvision DS-2CD1T43G2-LIU is a versatile bullet-style IP camera designed for both indoor and outdoor surveillance. With a 4.0MP high-resolution sensor, black-and-white night vision, and advanced security features, it ensures clear and reliable monitoring in various environments.

Camera Performance

• Sensor: 1/3 Inch Progressive Scan CMOS, delivering sharp images.
• Resolution: 2560 x 1440, providing 4.0MP high-definition video.
• Shutter Speed: 1/3s to 1/100,000s, optimizing exposure for different lighting.
• Day & Night: IR cut filter, automatically switching between modes.
• Night Vision: Yes, supports black-and-white night vision.
• S/N Ratio: >52 dB, reducing noise for clearer images.

Lens & Viewing Capabilities

• Lens: 6mm fixed lens.
• Focal Length: 6mm.
• Viewing Angles:
• Horizontal: 49°
• Vertical: 26°
• Diagonal: 57°
• PTZ (Pan-Tilt-Zoom): No.
• Zoom: 25x Optical Zoom, 16x Digital Zoom for flexible surveillance.

Image & Video Quality

• Frame Rate: 20-25 fps, ensuring smooth video streaming.
• Noise Reduction: 3D Digital Noise Reduction (DNR).
• Wide Dynamic Range (WDR): 120 dB, improving visibility in high-contrast lighting.
• Triple-Stream: Unmentioned.

Network & Connectivity

• Ethernet Port: 1 x RJ45 10M/100M self-adaptive Ethernet port.
• Wi-Fi: Not supported.
• Protocols Supported: TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP.

Security Features

• Password Protection: Yes, with encryption and authentication methods.
• Watermark: Yes, ensuring video integrity.
• Motion Detection: Yes, triggers alerts upon movement.
• Human Detection: Yes, enhances security by detecting people.
• Face Detection: Not specified.
• Security Protocols: Basic and digest authentication for HTTP, WSSE, host authentication (MAC address), security audit log.

Storage & Audio

• Card Slot: Not available.
• Storage Type: Unmentioned.
• Mic & Speaker: Only Mic for audio recording.
• Audio Communication: No.
• Input Trigger: Motion detection, video tampering alarm, exception.

Physical Build & Power

• Form Factor: Bullet, ideal for indoor & outdoor mounting.
• Body Material: Metal + Plastic, offering durability.
• Color: Black & White.
• Dimensions: 83.7 x 80.7 x 205.6mm.
• Weight: 580 gm.
• Relevant Accessories: Without Adapter & Wall Mount.

Power & Environmental Conditions

• Power Supply:
• 12 VDC ± 25%, 0.5 A, max. 6W.
• PoE (IEEE 802.3af, Class 3, max. 7W).
• Power Consumption: Approx. 7W.
• Operating Temperature: -30°C to 65°C.
• Operating Humidity: Up to 90% (non-condensing).

Warranty

• 1 Year Warranty (without adapter).
