Hikvision DS-2CD1343G2-LIU (2.8mm) (4.0MP) Smart Hybrid Light Fixed Turret Camera
Key Specification
‣ Usage - Outdoor
‣ Form-Factor - Turret
‣ Mega Pixels (MP) - 4.0
‣ Night Vision Mode - Black
and White
‣ Working Distance – 30
Meter
Product Specification
|
Brand |
Hikvision |
|
Model |
Hikvision
DS-2CD1343G2-LIU |
|
Usage |
Outdoor |
|
Type |
IP
Camera |
|
Camera |
Number of Camera: 1 Camera Type: Fixed Mega Pixels (MP): 4.0 Max. Camera Resolution: 2560 x 1440 Secondary Camera Type: Not Applicable Secondary Camera Mega Pixel (MP): Not
Applicable Secondary Camera Max Resolution: Not
Applicable Sensor Type: 1/3 Inch Progressive Scan CMOS Resolution: 2560 x 1440 Shutter Speed: 1s to 1/100,000s Slow Shutter: Unmentioned Day & Night: IR cut filter Night Vision: Yes Night Vision Mode: Black and White S/N Ratio: Unmentioned |
|
Lens |
Number
of Lens: Single Lens (Primary) Lens: 2.8mm Focal Length:
2.8 mm PTZ: No Zoom: Unmentioned Viewing
Angle: 98 Degree (H), 54 Degree (V), 114 Degree (D) |
|
Image |
Triple-Stream: Yes Frame Rate - 50 Hz: 20 fps, 25 fps, 60 Hz:
20 fps, 24 fps Noise Reduction: Yes Digital Noise Reduction (DNR): 3D DNR Wide Dynamic Range (WDR): 120 dB |
|
Network
& Connectivity |
Sim
Supported: No Sim
Network Type: Not Applicable Interface(s):
1 x RJ45 10M/100M self-adaptive Ethernet port Wi-Fi: No Wi-Fi
Details: No |
|
Security |
Security: Password protection, complicated
password, watermark, basic and digest authentication for HTTP, WSSE and
digest authentication for Open Network Video Interface, security audit log,
host authentication (MAC address) Password Protection: Yes Watermark: Yes Motion Detection: Yes Human Detection: Yes Face Detection: Unmentioned Lightning Protection: Unmentioned Surge Protection: Unmentioned Voltage Transient Protection: Unmentioned Simultaneous Live View: Up to 6 channels |
|
Technical
Data |
Video
Type: H.265+/ H.265/ H.264+/ H.264 Mic
& Speaker: Only Mic Audio
Communication: No Input
Trigger: Unmentioned Working
Distance: 30 Meter Protocols:
TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP,
SMTP |
|
Physical Attributes |
Form-Factor: Turret Card Slot: No Storage Type: No Storage Supported: Unmentioned Body Material: Metal + Plastic Color: White Dimensions: 110 x 89.2 mm Weight (gm): 340 gm Relevant Accessories (Not Included): Unmentioned |
|
Power |
Power: 12
VDC +/- 25%, 0.4 A, max. 5 W, 5.5 mm coaxial power plug, reverse polarity
protection, PoE: IEEE 802.3af, Class 3, max. 6.5 W Battery
Capacity: Not Applicable Battery
Backup: No Battery
Backup Time: Not Applicable Power
Supply: 12 VDC +/- 25%, 0.4 A, max. 5 W, 5.5 mm coaxial power plug, reverse
polarity protection, PoE: IEEE 802.3af, Class 3, max. 6.5 W Approx.
Power Consumption: 6.5W Operating
Temperature: -30 Degree C to 65 Degree C Operating
Humidity: Humidity 96% or less (non-condensing) |
|
Warranty |
1 Year (Without Adapter) |
|
* Product may vary with different
Kit or Version |
|
Product Details
Hikvision
DS-2CD1343G2-LIU IP Camera
The Hikvision DS-2CD1343G2-LIU
is an advanced outdoor IP camera offering 4.0MP resolution and 2560
x 1440 maximum resolution, delivering high-definition video surveillance
for various security needs.
Camera
Performance
- Sensor:
1/3 Inch Progressive Scan CMOS
- Resolution:
2560 x 1440 providing crisp and detailed images.
- Shutter Speed:
1s to 1/100,000s for flexible exposure control in varying light
conditions.
- IR Cut Filter:
Ensures accurate color representation in the daytime and optimal
black-and-white vision during the night.
- Night Vision:
Black and White mode for improved visibility in low-light
conditions.
- S/N Ratio:
Not mentioned.
Lens
& Viewing Capabilities
- Lens:
2.8mm fixed lens.
- Focal Length:
2.8mm.
- Viewing Angles:
- Horizontal FOV:
98°
- Vertical FOV:
54°
- Diagonal FOV:
114°
Quality
- Triple-Stream:
Supports Triple-Stream encoding for efficient video transmission.
- Frame Rate:
- 50 Hz:
20 fps at 2560 x 1440, 25 fps at 1920 x 1080.
- 60 Hz:
20 fps at 2560 x 1440, 24 fps at 1920 x 1080.
- Noise Reduction:
Equipped with 3D Digital Noise Reduction (DNR) for clearer images.
- Wide Dynamic Range (WDR): 120 dB for balanced exposure, ideal for
environments with mixed lighting.
Network
& Connectivity
- Ethernet Port:
1 x RJ45 10M/100M self-adaptive Ethernet port for stable wired
connectivity.
- Wi-Fi:
Not supported.
- Protocols:
Includes TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6,
and more for flexible network integration.
Security
Features
- Password Protection:
Supports password protection with strong security protocols.
- Watermark:
Allows for a watermark to be embedded in video feeds for additional
security.
- Motion Detection:
Detects motion in the camera’s field of view, sending alerts as needed.
- Human Detection:
Capable of detecting human figures for better-targeted alerts.
- Face Detection:
Not mentioned.
Storage
- Card Slot:
No card slot for external storage.
- Storage Type:
Not explicitly mentioned.
Physical
Build & Power
- Form Factor:
Turret design for easy mounting and installation.
- Body Material:
Metal + Plastic for durability.
- Color:
White.
- Dimensions:
110 x 89.2 mm.
- Weight:
340 gm.
- Power Consumption:
6.5W maximum powered via 12V DC or PoE (802.3af).
Operating
Conditions
- Operating Temperature:
-30°C to 65°C, designed for extreme weather conditions.
- Operating Humidity:
Up to 96% (non-condensing) for use in humid environments.
Warranty
- Comes with a 1-year warranty (without adapter).
