Hikvision DS-2CD1023G0-IUF IP Camera

The Hikvision DS-2CD1023G0-IUF is a fixed outdoor IP camera designed for robust surveillance needs. It offers 2.0MP resolution with high-quality 1080p video and advanced imaging technologies, ideal for monitoring both day and night.

Camera Performance

Equipped with a 1/2.7-inch Progressive Scan CMOS sensor, the camera delivers clear 1920 x 1080 resolution. It supports a shutter speed range from 1/3 s to 1/100,000 s and offers IR cut filter, making it suitable for day, night, auto, and scheduled modes for versatile monitoring. The night vision mode offers black and white visibility in low-light environments.

Lens & Viewing Capabilities

This camera features a 2.8mm lens with a wide viewing angle:

• Horizontal FOV: 112.1°
• Vertical FOV: 60°
• Diagonal FOV: 132.2° The lens provides a wide field of view, ensuring that a larger area is captured.

Network & Connectivity

The Hikvision DS-2CD1023G0-IUF includes a single RJ45 Ethernet port for 10M/100M self-adaptive Ethernet connectivity, but Wi-Fi connectivity is not supported. It is compatible with TCP/IP, HTTP, FTP, DHCP, DNS, and more for smooth integration into various network environments.

Video Quality

This camera supports H.265/H.264/MJPEG video compression formats for efficient video streaming and storage. It offers the following frame rates:

• Main stream: 25 fps at 50Hz or 30 fps at 60Hz (for 1920x1080 or 1280x720 resolution).
• Sub-stream: 25 fps at 50Hz or 30 fps at 60Hz (for 640x480 or 640x360 resolution). The 3D DNR and DWDR (Digital Wide Dynamic Range) technologies ensure crisp, clear video in varying lighting conditions.

Security Features

While security features like password protection, watermarking, and motion detection are not included, the camera provides video tampering alarms and exception triggers to enhance security.

Storage

This model supports microSD cards (up to 256GB) for onboard storage, eliminating the need for an external NVR in certain setups. It does not support cloud storage or other remote storage options.

Physical Build & Power

The camera is housed in a metal/plastic body, offering durability and resistance to outdoor conditions. It operates on 12V DC or PoE (Power over Ethernet), with a maximum power consumption of 6.5W.

Operating Conditions

The Hikvision DS-2CD1023G0-IUF is designed for a range of environmental conditions, though specific operating temperature and humidity details are not provided.

Warranty & Additional Information

The camera comes with a 1-year warranty (excluding the adapter). Please note, the product specifications may vary depending on the kit or version.
