Gigabyte B860M AORUS ELITE ICE (Wi-Fi 6E) DDR5 Intel Gaming Motherboard #B860M A ELITE WF6E ICE / B860M A ELT WF6E ICE / B860M AORUS ELITE WIFI6E ICE
Key Specification
Product Specification
|
Brand |
Gigabyte |
|
Model |
Gigabyte
B860M AORUS ELITE ICE (Wi-Fi 6E) |
|
Color |
White |
|
CPU Data |
Chipset
Brand: Intel Chipset:
Intel B860 Sockets
Supported: LGA1851 Built-in
Processor: N/A Supported
CPU: Intel Core Ultra Processors Generation:
Ultra |
|
Memory Support |
Memory Type: DDR5 Memory MHz: 9200(O.C)/ 8800(O.C)/ 8600(O.C)/
8400(O.C)/ 8266(O.C)/ 8200(O.C)/ 8000(O.C)/ 7950(O.C)/ 7900(O.C)/ 7800(O.C)/
7600(O.C.)/ 7400(O.C.)/ 7200(O.C.)/ 7000(O.C.)/ 6800(O.C.)/ 6600(O.C.)/ 6400/
5600 MT/s ECC , non-ECC, Un-buffered DIMM. Memory Channel: Dual Memory Slot: 4 Memory Max: 256GB |
|
Storage
Info |
Storage
Interface: 6Gb/s, M.2/SSD
Expansion Slot: 3 M.2/SSD
Expansion: 3 x M.2 (1 x M.2 connector (Socket 3, M key, type 2580/2280 PCIe
5.0 x4/x2 SSD support), 1 x M.2 connector (Socket 3, M key, type 2280 PCIe
4.0 x4/x2 SSD support), 1 x M.2 connector (Socket 3, M key, type
25110/22110/2580/2280 PCIe 4.0x4/x2 SSD support)) |
|
Graphics Info |
Multi-GPU Support: N/A PCI Express Slot: 1 x PCI Express x16 slot
supporting PCIe 5.0 and running at x16 (PCIEX16), 1 x PCI Express x16 slot
supporting PCIe 4.0 and running at x4 (PCIEX4) |
|
Audio
& Video |
Audio
Chipset: Realtek Audio CODEC Audio
Channel – 2/4/5.1/7.1 |
|
Network & Connectivity |
LAN Chipset: Realtek 2.5GbE LAN Speed (Mbps): 10/ 100/ 1000/ 2500Mbps WiFi: Yes WiFi Technology: Intel Wi-Fi 6E AX211 Bluetooth: Bluetooth 5.3 |
|
Ports Data |
USB
Port: 4 x USB 2.0/1.1 Type-A, 4 x USB 3.2 Gen 1 Type-A, 1 x USB 4 Type-C, 2 x
USB 3.2 Gen 2 Type-A VGA
Port: N/A HDMI
Port: 1 Display:
1 TPM: 1 SATA
Port: 4 |
|
Technical Data |
Cable Management: Front Heatsink: Yes RGB Support: ARGB RGB Connector: 3 x addressable RGB Gen2 LED
strip headers, 1 x RGB LED strip header Approx. Power Consumption: 60W Form Factor: Micro-ATX |
|
Compatibility |
Supported
Operating System: Windows 10 / Windows 11 Compatible
Products: Compatible with LGA1851 Sockets Intel Core Ultra Processors |
|
Warranty |
3 year |
|
* Product may vary with
different Kit or Version |
|
Product Details
Gigabyte
B860M AORUS ELITE ICE (Wi-Fi 6E) DDR5 Micro-ATX Motherboard
The Gigabyte B860M AORUS ELITE
ICE (Wi-Fi 6E) motherboard is engineered for high-performance computing,
featuring the latest Intel B860 chipset and LGA1851 socket. It is
optimized for Intel Core Ultra processors, delivering powerful and
efficient performance for gaming, content creation, and professional
applications.
Features
The Gigabyte B860M AORUS ELITE
ICE supports DDR5 memory, providing a significant boost in memory
bandwidth and overall system performance. It features support for up to
256GB of DDR5 RAM across 4 DIMM slots, offering scalability for
demanding workloads. With overclocking support for memory speeds up to 9200MHz
(OC), this motherboard delivers superior performance for multitasking,
gaming, and other high-performance applications.
Storage
and Expansion
This motherboard provides 3 M.2
slots, allowing for rapid SSD expansion. The M.2 connectors support PCIe
5.0 x4, PCIe 4.0 x4, and PCIe 4.0 x4/x2 standards, ensuring
fast data transfer rates for storage devices. It also includes a 6Gb/s
storage interface for additional SATA devices, expanding the possibilities
for storage configurations in your system.
Graphics
and Expansion
The Gigabyte B860M AORUS ELITE
ICE is equipped with 1 PCIe 5.0 x16 slot for high-performance
graphics cards, supporting modern GPUs for gaming and other graphics-intensive
tasks. It also includes a PCIe 4.0 x4 slot, providing flexibility for
adding additional expansion cards or accessories.
Networking
and Audio
This motherboard features Realtek
2.5GbE LAN, offering a fast and stable wired network connection
ideal for online gaming and data-heavy tasks. Additionally, it includes Intel
Wi-Fi 6E AX211 for superior wireless connectivity, providing blazing-fast
internet speeds. Bluetooth 5.3 support further enhances the system's
connectivity options, enabling seamless integration with wireless peripherals.
The Realtek Audio CODEC
onboard provides 7.1-channel high-definition audio, ensuring an
immersive sound experience for gaming, media consumption, and content creation.
Build
and Design
With a white aesthetic, the Gigabyte
B860M AORUS ELITE ICE motherboard is designed to complement modern builds
with its clean, sleek look. It features ARGB lighting support, including
3 addressable RGB Gen2 LED strip headers and 1 RGB LED strip header,
allowing users to customize their system's lighting. The motherboard also
includes heatsinks for efficient thermal management, ensuring that the
system stays cool under load.
Warranty
and Compatibility
This motherboard is compatible with Windows
10 and Windows 11, providing flexible options for your preferred
operating system. It supports Intel Core Ultra processors using the LGA1851
socket, ensuring that your system is ready for next-generation CPUs. The Gigabyte
B860M AORUS ELITE ICE motherboard comes with a 3-year warranty,
ensuring long-term reliability.
Price
and Availability
The Gigabyte B860M AORUS ELITE
ICE (Wi-Fi 6E) motherboard is available for purchase at Computer Village
Agrabad, Chattogram, Bangladesh. For the latest price and availability,
please check with the retailer.
