Gigabyte B860 EAGLE (Wi-Fi 6E) DDR5 (Intel Core Ultra LGA1851 Socket) Motherboard #B860 EAGLE WIFI6E
Key Specification
Product Specification
|
Brand |
Gigabyte |
|
Model |
Gigabyte
B860 EAGLE (Wi-Fi 6E) |
|
Color |
Black & Grey |
|
CPU Data |
Chipset
Brand: Intel Chipset:
Intel B860 Sockets
Supported: LGA1851 Built-in
Processor: N/A Supported
CPU: Intel Core Ultra Processors Generation:
Ultra |
|
Memory Support |
Memory Type: DDR5 Memory MHz: 9066(O.C)/8800(O.C) /8600(O.C) /
8400(O.C) /8266(O.C) / 8200(O.C) / 8000(O.C) / 7950(O.C) / 7900(O.C) /
7800(O.C) / 7600(O.C.) / 7400(O.C.) / 7200(O.C.) / 7000(O.C.) / 6800(O.C.) /
6600(O.C.) /6400/5600 MT/s non-ECC Un-buffered DIMM Memory Channel: Dual Memory Slot: 4 Memory Max: 256GB |
|
Storage
Info |
Storage
Interface: 6Gb/s, M.2/SSD
Expansion Slot: 3 M.2/SSD
Expansion : 3 x M.2 (1 x M.2 connector (Socket 3, M key, type 2580/2280 PCIe
5.0 x4/x2 SSD support), 1 x M.2 connector (Socket 3, M key, type 2280 PCIe
4.0 x4/x2 SSD support), 1 x M.2 connector (Socket 3, M key, type
25110/22110/2580/2280 PCIe 4.0x4/x2 SSD support)) |
|
Graphics Info |
Multi-GPU Support: N/A PCI Express Slot: 1 x PCIe 5.0 x16 with PCIe
UD Slot, 2 x PCIe 4.0 x1 slots |
|
Audio
& Video |
Audio
Chipset: Realtek Audio CODEC Audio
Channel – 2/4/5.1/7.1 |
|
Network & Connectivity |
LAN Chipset: Realtek 2.5GbE LAN Speed (Mbps): 10/ 100/ 1000/ 2500Mbps WiFi: Yes WiFi Technology: Intel Wi-Fi 6E AX211 Bluetooth: Bluetooth 5.3 |
|
Ports Data |
USB
Port: 1 x USB Type-C port, with USB 3.2 Gen 2x2 support, 1 x USB 3.2 Gen 2
Type-A port (red), 4 x USB 2.0/1.1 ports VGA
Port: N/A HDMI
Port: 1 Display:
1 TPM: 1 SATA
Port: 4 |
|
Technical Data |
Cable Management: Front Heatsink: Yes RGB Support: ARGB RGB Connector: 3 x addressable RGB Gen2 LED
strip headers, 1 x RGB LED strip header Approx. Power Consumption: 70W Form Factor: ATX |
|
Compatibility |
Supported
Operating System: Windows 10 / Windows 11 Compatible
Products: LGA1851 socket: Support for Intel Core Ultra Processors |
|
Warranty |
3 year |
|
* Product may vary with
different Kit or Version |
|
Product Details
Gigabyte
B860 EAGLE (Wi-Fi 6E) DDR5 ATX Motherboard
The Gigabyte B860 EAGLE (Wi-Fi
6E) motherboard offers exceptional features and robust performance,
designed to support Intel Core Ultra processors. Featuring the Intel
B860 chipset and LGA1851 socket, this motherboard is perfect for
high-performance applications like gaming, content creation, and professional
workloads.
Features
The Gigabyte B860 EAGLE (Wi-Fi
6E) motherboard supports DDR5 memory, providing up to 256GB of
memory across 4 DIMM slots. With speeds of up to 9066MHz (OC),
it allows users to overclock for improved performance. It offers excellent
memory scalability with Dual Channel architecture and supports various overclocking
options for enhanced memory bandwidth.
Storage
and Expansion
This motherboard is equipped with 3
M.2 slots, offering support for the latest PCIe 5.0 x4 and PCIe
4.0 x4 SSDs. The M.2 connectors cater to PCIe 5.0 and PCIe
4.0 standards, ensuring high-speed data transfer for gaming, content
creation, and other high-demand applications. Additionally, the 6Gb/s
storage interface provides support for SATA devices, enhancing
storage flexibility.
Graphics
and Expansion
The Gigabyte B860 EAGLE
motherboard includes 1 x PCIe 5.0 x16 slot for the latest
high-performance graphics cards, ensuring that you can enjoy gaming and other
GPU-intensive tasks. The motherboard is designed for single-GPU
configurations but offers 2 PCIe 4.0 x1 slots for additional
expansion cards.
Networking
and Audio
Equipped with Realtek 2.5GbE LAN,
the motherboard provides fast, stable wired connections for online
gaming and professional work. The inclusion of Intel Wi-Fi 6E AX211
technology ensures superior wireless performance, while Bluetooth 5.3
allows for seamless connections with peripherals like wireless headsets and
controllers.
The Realtek Audio CODEC
onboard offers 7.1-channel high-definition audio, providing an immersive
sound experience for gaming, music, and media consumption.
Build
and Design
The Gigabyte B860 EAGLE
features a sleek black and grey design, complemented by ARGB lighting
support. It includes 3 addressable RGB Gen2 LED strip headers and 1
RGB LED strip header for lighting customization. The motherboard comes with
heatsinks for better thermal management, ensuring that the system
remains cool during intensive tasks.
Warranty
and Compatibility
This motherboard is compatible with Windows
10 and Windows 11, providing flexibility in operating systems. It
supports Intel Core Ultra processors using the LGA1851 socket,
offering future-proofing for next-generation Intel processors. The Gigabyte
B860 EAGLE motherboard is backed by a 3-year warranty for reliable
long-term use.
Price
and Availability
The Gigabyte B860 EAGLE (Wi-Fi
6E) motherboard is available for purchase at Computer Village Agrabad,
Chattogram, Bangladesh. For the latest price and availability, please
check with the retailer.
