D-Link DES-F1010P-E 16-Port PoE Unmanaged Network Switch

The D-Link DES-F1010P-E is a 16-port unmanaged network switch designed for environments that require Power over Ethernet (PoE) capabilities. With PoE support on 8 ports and a compact, fanless design, it is ideal for small businesses or home office networks where power needs to be delivered alongside data over Ethernet cables, such as for IP cameras, access points, and VoIP phones.

Features

• 16 Ports: Equipped with 8 x 10/100 BASE-T PoE ports and 2 x 10/100 BASE-T uplink ports, the DES-F1010P-E supports both data transmission and PoE for powering devices.
• PoE Support: Delivers Power over Ethernet (PoE) to 8 devices, eliminating the need for separate power cables for PoE-compatible devices.
• Unmanaged: The unmanaged switch offers simple plug-and-play operation, making it suitable for users who need a hassle-free solution.
• Data Transfer Rate: Supports 10/100 Mbps data speeds, suitable for general network applications and smaller network setups.
• Transmission Method: Uses Store-and-Forward transmission for efficient and reliable data delivery.

Design and Build

• Compact Desktop Form Factor: The desktop design ensures flexibility for placement in small workspaces or home offices.
• Fanless Design: Silent operation, making it ideal for noise-sensitive environments like home offices.
• Indicators: Features LED indicators for Link/Activity per port, providing easy monitoring of network activity.

Power Efficiency

• Power Supply: The external power adapter provides 96W to power the switch and connected devices.
• Approx. Power Consumption: The device is designed to be energy-efficient while delivering both data and power to your devices.

Technical Specifications

• Total Ports: 16 Ports
• PoE Ports: 8 x 10/100 BASE-T PoE Ports
• Uplink Ports: 2 x 10/100 BASE-T Uplink Ports
• Network Standards:
• IEEE 802.3 (10BASE-T Ethernet)
• IEEE 802.3u (100BASE-TX Fast Ethernet)
• IEEE 802.3x (Flow Control)
• ANSI/IEEE 802.3 (NWay Auto-negotiation)
• Data Transfer Rate: 10/100 Mbps
• Switching Capacity: 2 Gbps
• Transmission Method: Store-and-Forward
• Form Factor: Desktop
• Body Color: Black
• Dimensions: 184 x 75 x 27 mm
• Weight: 0.95 kg

Power Attributes

• Power Supply: External power adapter (96W)
• Power Consumption: Energy-efficient operation

Package Contents

• 1 x D-Link DES-F1010P-E Network Switch
• 1 x User Manual

Warranty

1-Year Warranty (Without Adapter)
