Cudy GS1006P 6-Port Gigabit PoE Network Switch

The Cudy GS1006P is a high-performance network switch designed for small to medium-sized networks that require Gigabit Ethernet speeds and PoE (Power over Ethernet) functionality. With its 6 ports, including 4 PoE-enabled ports, this switch is an ideal solution for powering and connecting devices like IP cameras, VoIP phones, and wireless access points.

Key Features

The Cudy GS1006P comes with 4 Gigabit PoE ports and 2 Gigabit Ethernet ports, allowing you to connect both power-hungry devices and standard network devices with high-speed data transmission. The PoE functionality supports the IEEE 802.3af/at standards, delivering up to 15.4W per port, providing power and data connectivity over a single Ethernet cable, which helps simplify installations and reduce cable clutter.

Reliable & Efficient Performance

The switch supports IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, and IEEE 802.3x standards, ensuring reliable data transfer rates of 10/100/1000 Mbps. The store-and-forward transmission method optimizes packet delivery for enhanced network efficiency.

Compact & Convenient Design

With a compact form factor and a fanless design, the Cudy GS1006P is quiet and suitable for use in environments where noise is a concern. Its gray body and compact dimensions (200 x 118 x 44mm) make it ideal for desktop installations in offices or home networks.

Technical Specifications

• Total Ports: 6 x Ports
• PoE Ports: 4 x Gigabit PoE
• Ethernet Ports: 2 x Gigabit Ethernet
• PoE Standard: IEEE 802.3af/at
• Data Transfer Rate: 10/100/1000 Mbps
• Transmission Method: Store-and-Forward
• Connector Type: 6 x 10/100/1000 Mbps RJ45 ports
• Network Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
• Body Color: Gray
• Form Factor: Desktop
• Dimensions: 200 x 118 x 44mm
• Weight: 0.61 kg
• Power Supply: AC INPUT (100-240V) 50/60Hz

Package Contents

• 1 x Cudy GS1006P Switch
• 1 x Power Cord
• 1 x Installation Guide

Warranty

1-Year Warranty (Without Adapter)
