Canon Lm36 36 Inch Color Large Format Scanner

(0 reviews)

Key Specification

  Scanning Speed (B & W) – 200dpi Draft: 1ips, 300dpi Standard: 0.5ips, 600dpi Best: 0.33ips

  Scanning Speed (Color) – 200dpi Draft: 3ips, 300dpi Standard: 1.5ips, 600dpi Best: 1ips

  Scan Size Max. – A0

  ADF - Unmentioned

  Sheet Capacity (ADF) – Unmentioned

  Interface (Built-in) – USB, LAN





Contact : 01713-240734
Price
৳280,000.00 /1
Quantity
Total Price
Share

Product Specification

Brand

Canon

Model

Canon Lm36

Type

Large Format Scanner

Functions

Scanning

Scan Performance

Scan Technology: SingleSensor with multiple LED Illumination

Scanning Speed (B & W): 200dpi Draft: 1ips, 300dpi Standard: 0.5ips, 600dpi Best: 0.33ips

Scanning Speed (Color): 200dpi Draft: 3ips, 300dpi Standard: 1.5ips, 600dpi Best: 1ips

Resolution: 600dpi

Scan Size: Minimum: 3.2 x 6 Inch / 8.1 x 15.2 cm, Maximum: 38 x 109 Inch / 96.5 x 276.9 cm

Scan Size Max: A0

Color Bit Depth: 24-bit output

Grayscale Bit Depth: 16-Bit (Internal)

Color Scanning: Yes

Scanning Capability: Color, Grayscale, Monochrome

Paper Information

ADF: Unmentioned

Sheet Capacity (ADF): Unmentioned

Performance Characteristics

Light Source Type: LED (CIS)

Control Panel: LCD and buttons

Storage & Interface

Interface (Built-in): USB, LAN

USB Type: Unmentioned

Technical Info

Button: Unmentioned

Optical Density: CIS (Contact Image Sensor)

Twain Compatibility: Yes

MCBF: Unmentioned

Supported Operating System: Windows 7 (32-/64-Bit)/ Windows 8 (32-/64-Bit)/ Windows 10 (32-/64-Bit)/ Windows 11 (64-Bit Only)/ Windows Server 2008 R2/ Windows Server 2012/ Windows Server 2012 R2/ Windows Server 2016/ Windows Server 2019/ Windows Server 2022 (64-Bit Only)/ macOS 10.13

Power*

Operating Temperature Range: 10 - 32.5 degree C

Power Supply: 100 to 240 VAC, 50 / 60 Hz, AC Adapter

Rated Voltage: Unmentioned

Approx. Power Consumption: 0.6W (Sleep), 11.7W (Ready), 17.5W (Maximum)

Physical Description*

Color: Black & White

Dimensions: 1237 x 132 x 254mm

Weight (Kg): 6.6 kg

Warranty

1 Year (Without Adapter) (Box Mandatory While Claiming)

* Product may vary with different Kit or Version

Product Details

Canon Lm36 Large Format Scanner

The Canon Lm36 is a large format scanner designed for businesses and professionals who need to scan oversized documents, including architectural plans, engineering drawings, posters, and other large-format materials. Its advanced scanning technology ensures high-quality results for documents up to A0 size.

Scanning Performance

  • Scan Technology: SingleSensor with multiple LED illumination for clear and accurate imaging.
  • Scanning Speed:
    • Black & White (B/W):
      • 200 dpi Draft: 1 inch per second (ips)
      • 300 dpi Standard: 0.5 ips
      • 600 dpi Best: 0.33 ips
    • Color:
      • 200 dpi Draft: 3 ips
      • 300 dpi Standard: 1.5 ips
      • 600 dpi Best: 1 ips
  • The scanner offers high-speed scanning suitable for handling large documents without sacrificing image quality.

Resolution and Scanning Capabilities

  • Maximum Resolution: 600 dpi
  • Scanning Size Range:
    • Minimum Size: 3.2 x 6 inches (8.1 x 15.2 cm)
    • Maximum Size: 38 x 109 inches (96.5 x 276.9 cm)
  • The Canon Lm36 supports a wide range of scanning sizes, making it ideal for scanning extra-large documents like blueprints, maps, and banners.

Color and Grayscale Scanning

  • Color Bit Depth: 24-bit output for rich, true-to-life colors.
  • Grayscale Bit Depth: 16-bit internal for precise shading and details.
  • Supports color, grayscale, and monochrome scanning for versatile use cases.

Performance Characteristics

  • Light Source: Uses LED (CIS) for optimal brightness and energy efficiency.
  • Control Panel: LCD and buttons for intuitive operation.
  • Scanning Capability: Capable of scanning in color, grayscale, and monochrome.

Storage & Interface

  • Interfaces: Equipped with USB and LAN for easy connection to computers and networks.
  • USB Type: Information on USB type is unmentioned, but the scanner supports high-speed data transfer.

Compatibility

The Canon Lm36 is compatible with the following operating systems:

  • Windows: Windows 7 (32-/64-bit), Windows 8 (32-/64-bit), Windows 10 (32-/64-bit), Windows 11 (64-bit only), and various Windows Server versions (2008 R2, 2012, 2012 R2, 2016, 2019, and 2022).
  • macOS: Version 10.13 and later.

Power Specifications

  • Power Supply: 100 to 240 VAC, 50/60 Hz (AC Adapter)
  • Approximate Power Consumption:
    • Sleep Mode: 0.6W
    • Ready Mode: 11.7W
    • Maximum: 17.5W This energy-efficient power consumption makes the Canon Lm36 an environmentally friendly option for large-format scanning needs.

Physical Description

  • Color: Black & White
  • Dimensions: 1237 x 132 x 254 mm
  • Weight: 6.6 kg Despite its large scanning capacity, the Canon Lm36 is designed to be compact and space-efficient, making it suitable for offices with limited space.

Warranty

The Canon Lm36 comes with a 1-year warranty (excluding the adapter), and the original box is required for warranty claims.
