Asus PRIME H610M-F D4 R2.0 DDR4 Intel Motherboard
Key Specification
Product Specification
|
Brand |
Asus |
|
Model |
Asus
PRIME H610M-F D4 R2.0 |
|
Color |
Black |
|
CPU Data |
Chipset
Brand: Intel Chipset:
Intel H610 Sockets
Supported: LGA1700 Built-in
Processor: Unmentioned Supported
CPU: Intel Core 14th & 13th Gen Processors, Intel Core 12th Gen, Pentium
Gold and Celeron Processors Generation:
12th/13th/14th |
|
Memory Support |
Memory Type: DDR4 Memory MHz: 3200/ 3000/ 2933/ 2800/ 2666/
2400/ 2133 Non-ECC, Un-buffered Memory Memory Channel: Dual Memory Slot: 2 Memory Slot (Additional Info): Unmentioned Memory Max: 64GB Optane Memory Support: Unmentioned |
|
Storage
Info |
Storage
Interface: 6Gb/s M.2/SSD
Expansion Slot: 1 M.2/SSD
Expansion Slot Details: 1 x M.2 (M.2 slot (Key M), type 2242/2260/2280
(supports PCIe 3.0 x4 mode)) |
|
Graphics Info |
Graphics: Integrated Graphics Chipset: Integrated With Processor Multi-GPU Support: Unmentioned PCI Express Slot: 1 x PCIe 4.0 x16, 1 x PCIe
3.0 x1 |
|
Audio
& Video |
Audio
Chipset: Realtek 7.1 Surround Sound High Definition Audio CODEC Audio
Channel – 7.1 |
|
Network & Connectivity |
LAN Chipset: 1 x Realtek 1Gb LAN Speed (Mbps): 10 / 100 / 1000Mbps WiFi: Unmentioned WiFi Technology: Unmentioned Bluetooth: Unmentioned |
|
Ports Data |
USB Port: 2 x USB 5Gbps Type-A, 4 x USB 2.0 Type-A VGA Port: Unmentioned DVI
Port: Unmentioned HDMI
Port: 1 DisplayPort
(DP): Unmentioned IDE
Port: Unmentioned SATA
Port: 2 x SATA Thunderbolt:
Unmentioned TPM
Port: Unmentioned |
|
Technical Data |
Back-Connect Design: Unmentioned Cable Management: Front Heatsink: Unmentioned FireWire: Unmentioned CrossFire Support: Unmentioned Sli Support: Unmentioned RGB Support: Unmentioned RGB Connector: Unmentioned Approx. Power Consumption: 60W Form Factor: Micro-ATX |
|
Compatibility |
Supported
Operating System: Windows 11, 10 Compatible
Products: 12th/ 13th/ 14th Gen Intel Core i9/ i7/ i5/ i3 and Pentium/ Celeron
processors in the LGA1700 |
|
Warranty |
3 Year Replacement Warranty |
|
* Product may vary with
different Kit or Version |
|
Product Details
Asus
PRIME H610M-F D4 R2.0 Micro-ATX Motherboard
The Asus PRIME H610M-F D4 R2.0
motherboard provides solid performance and excellent connectivity for building
budget-friendly or mid-range PCs. Supporting Intel 12th, 13th,
and 14th Gen processors, it is ideal for users looking to build a
versatile system with reliable memory and storage options.
Features
• Processor Support:
Supports Intel Core 12th, 13th, and 14th Gen processors along with Pentium
Gold and Celeron processors via the LGA1700 socket.
• Memory Support:
Supports DDR4 memory with speeds up to 3200 MHz and a maximum
capacity of 64GB.
• Audio:
Realtek 7.1 Surround Sound High Definition Audio CODEC for immersive
audio experience.
Storage
and Expansion
• M.2 Slot:
1 x M.2 Slot (Key M) for fast PCIe 3.0 x4 SSD storage (supports 2242/2260/2280
form factors).
• SATA Ports:
2 x SATA ports for additional storage drives.
Graphics
and Expansion
• Integrated Graphics:
Supports integrated graphics when paired with compatible processors.
• PCIe Slots:
1 x PCIe 4.0 x16 slot for high-performance expansion cards such as
graphics cards.
1 x PCIe 3.0 x1 slot for additional expansion cards.
Connectivity
Options
• USB Ports:
2 x USB 5Gbps Type-A ports for fast data transfer.
4 x USB 2.0 Type-A ports for additional device connections.
• Video Outputs:
1 x HDMI port for video output.
Network
and Audio
• LAN Chipset:
Realtek 1Gb Ethernet for stable and fast internet connections with 10/100/1000
Mbps speeds.
• Audio Chipset:
Realtek 7.1 Surround Sound for high-definition audio.
Design
and Build
• Form Factor: Micro-ATX
• Power Consumption: Approx. 60W
• Cable Management: Front cable management for easy setup.
Compatibility
• Supported Operating System:
Windows 11, Windows 10
• Compatible Products:
Compatible with Intel Core i9/i7/i5/i3, Pentium, and Celeron
processors of the 12th, 13th, and 14th Gen in the LGA1700 socket.
Warranty
Information
• Warranty: 3-year replacement warranty.
Price
and Availability
The Asus PRIME H610M-F D4 R2.0
motherboard offers an affordable solution for users building systems with
Intel's latest processors. Available at authorized retailers for a reasonable
price.
