ASUS H510M-F R3.0 Intel LGA 1200 10th &11th Gen mATX Motherboard

(0 reviews)

Key Specification

§  Intel® H470 Chipset

§  Intel® LGA1200 10th & 11th Gen CPU Support

§  2x DDR4- 3200MHz Support (Maximum 64GB)

§  1x HDMI Output

§  mATX From Factor

Contact : 01713-240726
Price
৳10,200.00 /1
Quantity
(5 available)
Total Price
Share

Product Specification



Model

PRIME H510M-F R3.0

CPU Support

Intel® Socket LGA1200 for 11th Gen Intel® Core™ Processors & 10th Gen Intel® Core™, Pentium® Gold and Celeron® Processors, Supports up to Intel® 65W CPU

Chipset

Intel® H470 Chipset

Form Factor

mATX Form Factor, 8.9-inch x 7.7 inch (22.6 cm x 19.6 cm)

Memory Support

2 x DIMM slots, Max. 64GB, DDR4 3200(OC)/3000(OC)/2933/2800/2666/2400/2133 Non-ECC, Un-buffered Memory

Dual Channel Memory Architecture

Supports Intel® Extreme Memory Profile (XMP)

Storage Support

M.2 slot (Key M), type 2242/2260/2280 (supports PCIe 3.0 x4 & SATA modes)

M.2 Socket

M.2 slot (Key M), type 2242/2260/2280 (supports PCIe 3.0 x4)

4 x SATA 6Gb/s ports

Graphics

1 x HDMI™ port

Network

1 x Realtek 1Gb Ethernet

PCI

1 x PCIe 4.0/3.0 x16 slot

1 x PCIe 3.0 x1 slot

Internal Connectors

1 x 4-pin CPU Fan header

1 x 4-pin Chassis Fan header

1 x 24-pin Main Power connector

1 x 4-pin +12V Power connector

1 x M.2 slot (Key M)

4 x SATA 6Gb/s ports

1 x USB 5Gbps header supports 2 additional 5Gbps ports

1 x USB 2.0 header supports 2 additional USB 2.0 ports

1 x Clear CMOS header

1 x Front Panel Audio header (F_AUDIO)

1 x Speaker header

1 x SPI TPM header (14-1 pin)

1 x 10-1 pin System Panel header

Back Panel Ports

4 x USB 5Gbps ports (4 x Type-A)

2 x USB 2.0 ports (2 x Type-A)

1 x HDMI™ port

1 x Realtek 1Gb Ethernet port

3 x Audio jacks

1 x PS/2 Keyboard (purple) port

1 x PS/2 Mouse (green) port

Audio

Realtek 7.1 Surround Sound High-Definition Audio CODEC

Audio Shielding

Dedicated audio PCB layers

USB

Rear USB (Total 6 ports)

4 x USB 5Gbps ports (4 x Type-A)

2 x USB 2.0 ports (2 x Type-A)



Front USB (Total 4 ports)

1 x USB 5Gbps header supports 2 additional USB 5Gbps ports

1 x USB 2.0 header supports 2 additional USB 2.0 ports

BIOS

128 Mb Flash ROM, UEFI AMI BIOS

Special Features

ASUS 5X PROTECTION III

- DIGI+ VRM

- LANGuard

- Overvoltage Protection

- SafeSlot Core

- Stainless-Steel Back I/O



ASUS Q-Design

- Q-DIMM

- Q-LED Core

- Q-Slot



ASUS Thermal Solution

- Aluminum heatsink design

Software Features

ASUS Exclusive Software

Armoury Crate

AI Suite 3

- Performance And Power Saving Utility

 TurboV EVO

 EPU

 DIGI+ VRM

- EZ update

ASUS CPU-Z

Norton 360 Deluxe (60 Days Free Trial)

WinRAR (40 Days Free Trial)



UEFI BIOS

ASUS EZ DIY

- ASUS CrashFree BIOS 3

- ASUS EZ Flash 3

- ASUS UEFI BIOS EZ Mode

Warranty

03 years warranty



Product Details

ASUS PRIME H510M-F R3.0 motherboard is designed for users seeking a stable and efficient platform for Intel® 10th and 11th Gen processors. With support for Intel® Core™ processors, including Pentium® Gold and Celeron® chips, this motherboard is a reliable choice for both personal and professional computing needs.

CPU and Chipset Support

This motherboard is equipped with the Intel® H470 chipset and supports Intel® Socket LGA1200, enabling compatibility with 11th Gen and 10th Gen Intel® Core™ processors. It can handle CPUs with a power rating of up to 65W, providing enough headroom for a range of computing tasks.

Memory Support

The PRIME H510M-F R3.0 features 2 x DIMM slots, supporting up to 64GB of DDR4 memory with speeds of 3200(OC)/3000(OC)/2933/2800/2666/2400/2133 MHz. The Dual Channel Memory Architecture ensures faster data transfer, improving overall system performance. Additionally, the motherboard supports Intel® Extreme Memory Profile (XMP) for advanced memory overclocking.

Storage and Expansion

The motherboard offers ample storage options with 1 x M.2 slot (Key M) that supports both PCIe 3.0 x4 and SATA modes. Alongside the M.2 slot, 4 x SATA 6Gb/s ports provide flexibility for connecting additional drives and storage devices. Whether you're building a high-performance machine or need more space for files, the H510M-F R3.0 ensures adequate storage solutions.

Graphics and Display

The motherboard comes with a 1 x HDMI™ port for connecting displays, ensuring high-quality video output. It’s ideal for users who need a straightforward visual connection without the need for discrete graphics cards.

Network and Connectivity

Featuring Realtek 1Gb Ethernet, the PRIME H510M-F R3.0 ensures reliable and fast network connectivity for browsing, gaming, and data transfer. It also offers a solid range of USB ports, including 4 x USB 5Gbps and 2 x USB 2.0 ports on the back panel, with additional support for USB headers that allow for extra connections.

Special Features

The ASUS 5X Protection III ensures reliability and durability with features like DIGI+ VRM, SafeSlot Core, and Overvoltage Protection. The motherboard also includes a thermal solution with an aluminum heatsink design for efficient cooling.

Software and BIOS

With ASUS Armoury Crate and AI Suite 3, users can optimize performance and manage system settings easily. The UEFI BIOS features EZ Flash 3 and CrashFree BIOS 3 for convenient updates and system recovery.

Warranty

The ASUS PRIME H510M-F R3.0 is backed by a 3-year warranty, ensuring long-term reliability for your system.

This motherboard combines robust performance, expandability, and user-friendly features, making it an excellent choice for anyone looking to build a high-performance system.
